3- OKK HM 80S 4 AXIS CNC HMC'S
No longer available
3- OKK HM 80S 4 AXIS CNC HMC'S
Harbor Springs, MI
Description
EQUIPPED WITH
Fanuc 16i-M CNC Control
(40) Position Automatic Tool Changer
Coolant Through Spindle 1000 PSI
Specifications
Manufacturer | OKK |
Model | HM 80S |
Condition | Used |
Stock Number | 103619 |
Spindle taper | 50 |
X-axis travel | 39.37" |
Y-axis travel | 33.46" |
Z-axis travel | 32.28" |
Spindle speeds | 13,000 RPM |
Table indexing | 1 Degree |
(2) pallet size | 31.5" x 31.5" |
Y-axis digital servo motor | 6.1/7.8 HP |
X, y & z-axis maximum thrust | 3.945 Lbs |
X & z-axis digital servo motor | 6.1/6.7 HP |
Maximum load capacity on pallet | 2,424 Lbs. |
Spindle drive motor (cont./30 min.) | 40/33.5 HP |
Distance - table top to spindle center | 1.2" - 34.6" |
Distance - table center to spindle nose | 7.9" - 40.2" |
