2002 SCHMID T-630 RACK FORMING PRESS

2002 SCHMID T-630 RACK FORMING PRESS

Contact us for price

Harbor Springs, MI

orCall 1-231-526-7135 fax

Description

TOTAL FORCE 8000 Kn LOWER EJECTOR 1000 kN UPPER EJECTOR 95 kN RAM FOR FORMING MAX 240mm RANGE OF ADJUSTABLE RAM STOP 100mm RAM TOTAL MAX 248 mm LOWER EJECTOR MAX 115 MM UPPER EJECTOR MAX 30mm FAST APPROACH SPEED 150 mm's FAST RETUN SPEED 200 mm's FORMING SPEED MAX 22 mm's ORBITAL FREQUENCY MAX 280 1/'MIN FRONT SPACE BETWEEN RAM GUIDES 600mm sIDE SPACE BETWEEN RAM GUIDES 550MM GREATEST DISTANCE BETWEEN RAM & ORBITAL HEAD 340MM DIAM. OF STEERING RACK MAX 32 MM LENGTH FROM TOOL CENTER-HYDRAULIC STOPPER 440-700mm LENGTH FROM TOOL CENTER-FIXED STOPPER 100-250MM 3 X 460 V/ 60 Hz POWER CONSUMPTION MAX LOAD 25 KW

Specifications

ManufacturerSCHMID
ModelT-630 RACK FORMING PRESS
Year2002
ConditionUsed
Stock Number103514
