2002 HWACHEON MEGA 95 2-AXIS CNC FLAT BED LATHE

Contact us for price

orCall 1-231-526-7135 fax

Description

HWACHEON MEGA 95 2-AXIS CNC FLAT BED LATHE YEAR 2002 STOCK#103914 SPECIFICATIONS: SWING OVER BED .......................................................... 38.6" SWING OVER CROSS SLIDE ............................................. 26.2" SWING OVER GAP .......................................................... 48.4" MAX. DISTANCE BETWEEN CENTERS .............................. 153" MAX. TURNING DIAMETER ............................................ 25.6" X-AXIS TRAVEL ...............................................................19.09" Z-AXIS TRAVEL ...............................................................153" WORKPIECE WEIGHT CAPACITY BETWEEN CENTERS ...... 11,023 LBS MAX WEIGHT CAPACITY WITH ONE STEADY REST ......... 14,330 LBS MAX WEIGHT CAPACITY WITH TWO STEADY REST ........ 17,636 LBS RAPID TRAVERSE X/Z ....................................................236 IPM SPINDLE SPEEDS (3) RANGES ....................................... 40 - 1,000 RPM SPINDLE NOSE ............................................................. A2-15 HOLE THROUGH THE SPINDLE ..................................... 6" AUTOMATIC TURRET CAPACITY ................................... 12 STATIONS TAILSTOCK QUILL TRAVEL ............................................ 10.2" TAILSTOCK QUILL TAPER .............................................. #6 MT DIMENSIONS ............................................................... 315" L X 98" W X 85" TALL MACHINE WEIGHT ...................................................... 29,000 LBS EQUIPPED WITH: FANUC 21iT CNC ( i-Series Electronic ) CONTROL 24" 3-JAW MANUAL CHUCK (2) ROLLER TYPE STEADY RESTs TAILSTOCK * COOLANT SYSTEM 40 HP SPINDLE MOTOR

Specifications

ManufacturerHWACHEON
ModelMEGA 95 2-AXIS CNC FLAT BED LATHE
Year2002
ConditionUsed
Stock Number103914
