OKUMA Multus U4000 2SW2000 Multitasking CNC Lathe W/ Milling Head, Big Bore, Sub Spindle, Lower Turret
No longer available
OKUMA Multus U4000 2SW2000 Multitasking CNC Lathe W/ Milling Head, Big Bore, Sub Spindle, Lower Turret
Description
OKUMA Multus U4000 2SW2000 Multitasking CNC Lathe
YEAR 2014
STOCK# 103924
SPECIFICATIONS
Distance Between Centers: 78.74"
Max. Machining Diameter: 25.59"
Max. Machining Length: 78.74"
Hole Through Spindle: 5.5"
X-Axis (Upper): 27.36"
X-Axis (Lower): 9.25"
Y-Axis: 5.91"
W-Axis (sub spindle): 79.69"
Main Spindle Speed: 3000rpm
Main Spindle Mount: A2-11
Main Spindle Power: 32/22 kW (20min/continuous)
Sub Spindle Speed: 38-3800 rpm
Sub Spindle Mount: A2-8
Sub Spindle Power: 22/15 kW (29min/continuous)
Milling Turret Speed: 50-12,000rpm
Milling Turret Mount: Capto C6
Milling Turret Power: 22/15/11 kW (3min/15min/continuous)
ATC Magazine: 2x40 tools for 80 tool capacity
Machine size: 243" long x 121" deep x 120" high
Machine weight: 44,000lbs
EQUIPPED WITH:
OSP-P300SA CNC Control
Patrol Light
2 Line High Pressure Coolant (upper and lower turret)
Mist Collection
480V Transformer
Chip Conveyor
Hydraulic Oil Chiller
Spindle Oil Chiller
Pneumatic Assisted Door
Many Software Add-ons Including Gear Skiving and 3D Coordinate Conversion
5400 Hours Milling Turret
2600 Hours Main Spindle
Specifications
Manufacturer | OKUMA |
Model | Multus U4000 2SW2000 Multitasking CNC Lathe W/ Milling Head, Big Bore, Sub Spindle, Lower Turret |
Condition | Used |
Stock Number | 103924 |
Hours | 2600/5400 |
