ABB IRB 6640 6 AXIS CNC ROBOT 205KG X 2.75 REACH IRC5 CONTROLS
No longer available
ABB IRB 6640 6 AXIS CNC ROBOT 205KG X 2.75 REACH IRC5 CONTROLS
Harbor Springs, MI
Description
Robot Motion Speed
J1 100 °/s (1.75 rad/s)
J2 90 °/s (1.57 rad/s)
J3 90 °/s (1.57 rad/s)
J4 170 °/s (2.97 rad/s)
J5 120 °/s (2.09 rad/s)
J6 190 °/s (3.32 rad/s)
Robot Motion Range
J1 ±170°
J2 +85° - 65°
J3 +70° - 180°
J4 ±300°
J5 ±120°
J6 ±360°
If you are looking to decrease your maintenance costs and improve path
performance, then the ABB IRB 6640-205 IRC5 is ready to do the job!
Whether it is material handling, machine tending, or spot welding, the
IRB 6640-205 will fit into your dense production line without any
fear of collisions. It uses its advanced software programs, TrueMove
and Quick Move, to produce extreme collision avoidance, reduce the
risk of overload, and increase the precision of its path performance.
The need for a customized system is easy to develop with the upper arm
extenders and different wrist modules that are available.
Also,
safety is taken care of with features such as as load identification,
Specifications
Manufacturer | ABB |
Model | IRB 6640 6 AXIS CNC ROBOT 205KG X 2.75 REACH |
Year | 2012 |
Condition | Used |
Stock Number | 103651 |
Axes | 6 |
H-reach | 2750.00mm |
Payload | 205.00kg |
Mounting | Floor |
Structure | Articulated |
Robot mass | 1310.00kg |
Repeatability | ±0.0700mm |
